244
a) Linked to the pattern number selected using the [Mix Pattern
Select] button.
3 Press the [Mix Pattern Select] button.
A pattern selection window appears.
4 Set the button for the target pattern to the on state.
Dedicated patterns 1 to 24 are the same as standard
wi
pe patterns 1 to 24.
5 Press [OK].
6 Press the [Color 1] button and set color 1 using the
following parameters.
The [Color 1] button parameters are common to the
[Fl
at Color] buttons in the [Matte] group.
7 Press the [Color 2] button and set color 2 using the
following parameters.
To swap color 1 and color 2 in a color mix
Set the [Color Invert] button to the on state.
To set the pattern position (Position)
Set the [Position] button to the on state and set the
fo
llowing parameters.
To replicate a pattern (Multi)
You can replicate a pattern horizontally, vertically, or
bot
h up to 63 times.
For details about pattern layouts, see “Replicating a wipe
pattern (Multi)” (page 159).
Set the [Multi] button to the on state and set the following
p
arameters.
To set the aspect ratio of a pattern (Aspect)
Set the [Aspect] button to the on state and set the
f
ollowing parameter.
To rotate a pattern (Rotation)
In the [Rotation] group, select a rotation type.
Angle: Incl
ine a pattern at a fixed angle.
Speed: Rot
ate a pattern at a fixed speed.
When the [Angle] button is selected, set the following
p
arameter.
When the [Speed] button is selected, set the following
p
arameter.
2 Soft Softness of the pattern
contour
5 Pattern Pattern number
a)
Note
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Hue Hue
Note
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Hue Hue
No. Parameter Adjustment
1 Position H Horizontal position
• Negative values move left.
• Positive values move right.
2 Position V Vertical position
• Negative values move down.
• Positive values move up.
No. Parameter Adjustment
No. Parameter Adjustment
1 H Multi Number of repetitions of pattern
ho
rizontally
2 V Multi Number of repetitions of pattern
ve
rtically
3 Invert Type Pattern layout (1 to 4)
No. Parameter Adjustment
1 Aspect Aspect ratio
• Negative values expand
ve
rtically.
• Positive values expand
ho
rizontally.
No. Parameter Adjustment
1 Angle Inclination angle of pattern
• A value of –100.00 corresponds
to
a rotation of one turn
counterclockwise.
• A value of +100.00
c
orresponds to a rotation of one
turn clockwise.
• A value of 0.00 corresponds to
no
rotation.
No. Parameter Adjustment
1 Speed Rotation speed of pattern
• A value of –100.00 corresponds
to
1 revolution/second
counterclockwise rotation.
• A value of +100.00
c
orresponds to 1 revolution/
second clockwise rotation.
• A value of 0.00 corresponds to
no
rotation (stationary).
