37
Three-dimensional transform operation mode
This mode is used for three-dimensional transform
op
erations on images using a DME.
For details about DME operations, see “Three-
Dimensional Transforms” (page 199).
Center CTR • When the [CTR] button is
pressed once:
Adjusts the two-dimensional
transform parameters to the
detent positions.
• When the [CTR] button is
pre
ssed twice, or the [CTR]
button is pressed once while
pressing the [SHIFT] button:
Returns the two-dimensional
t
ransform parameters to the
default values.
• When the [BDR/CROP] button
is
lit green, the [CTR] button
selects the edge (bottom edge)
to crop.
Border/
Cro
p
BDR/
CROP
• When the [BDR/CROP] button
is pressed (lit amber):
Adjusts the border width of a
key using the trackball or
Z-ring.
• When the [BDR/CROP] button
is
pressed while pressing the
[SHIFT] button (lit green):
Adjusts the crop width of a key
us
ing the Z-ring.
Function
name
Button
name
Description
Local LOCAL Selects local space.
Global GLB Selects global space.
Source SRC Selects source space.
Target TRGT Selects target space.
Aspect/
Perspective
ASP PERS • When the [ASP PERS] button
is pressed in source space:
Adjusts the aspect ratio of an
image using the trackball or
Z-ring.
• When the [ASP PERS] button
is
pressed while pressing the
[SHIFT] button in source
space:
Adjusts the skew of an image
u
sing the trackball.
• When the [ASP PERS] button
is pressed in target space:
Adjusts the viewpoint position
(pe
rspective of an image)
using the trackball or Z-ring.
Function
name
Button
name
Description
Location
Size
LOC SIZE • Moves an image using the
trackball.
• Scales an image (shrink/
magnify) using the Z-ring.
Location
XYZ
LOC XYZ Moves an image using the
tra
ckball or Z-ring.
Rotation ROT Rotates an image using the
tra
ckball or Z-ring.
Shift SHIFT Used in combination with the
[AS
P PERS], [ROT], [CTR], and
[CLR WORK BUFR] buttons.
Clear Work
Buffe
r
CLR
WORK
BUFR
• When the [CLR WORK BUFR]
button is pressed once:
Returns the three-dimensional
t
ransform parameters to the
initial settings.
• When the [CLR WORK BUFR]
b
utton is pressed twice, or the
[CLR WORK BUFR] button is
pressed once while pressing
the [SHIFT] button:
Returns all DME parameters to
th
e initial settings.
Axis
Loc
ation
AXIS LOC Moves the rotation axis of an
image using the trackball or
Z-ring.
X
Y
Z
X
Y
Z
• Restricts the parameters
t
argeted by the operation.
When the [X] button is lit:
Operations on parameters on
t
he X-axis using the trackball
are enabled.
When the [Y] button is lit:
Operations on parameters on
t
he Y-axis using the trackball
are enabled.
When the [Z] button is lit:
Operations on parameters on
t
he Z-axis (Z-ring adjustment
items) using the Z-ring are
enabled.
• When the [X] button, [Y]
button, and [Z] button are lit
green, you can enter
parameter settings using the
numeric keypad control block.
Fine FINE
Switches to fine mode, enabling
fine adjustment control of setting
values using the trackball and
Z-ring.
Function
name
Button
name
Description
