Sony MLS-X1 User Manual

38
Menu parameter operation mode
Used to set menu parameters.
For details about menu parameter operations, see
“Setting Parameters” (page 74).
Device/frame memory/clip player operation
mo
de
This mode controls operations of devices such as VTRs/
d
isk recorders and operations of frame memory/clip
players.
For details about device operations, see “Control of
VTRs and Disk Recorders” (page 217).
For details about frame memory operations, see “Playing
Video” (page 184).
For details about clip player operations, see “Playing
Video” (page 191).
c Tra
ckball
This adjusts the parameters of items selected in resizer
oper
ation mode, three-dimensional transform operation
mode, and menu parameter operation mode.
d Z-
ring
This adjusts the parameters of items selected in resizer
oper
ation mode, three-dimensional transform operation
mode, and menu parameter operation mode.
It is used for playback operations in device/frame
memory/
clip player operation mode.
It can control an effect timeline in run control operation
mode.
e Di
splay
Resizer operation mode
The following information is displayed.
• Reference switcher bank name: M/E1 to M/E5, P/P
• Reference resizer name: KEY1 RSZR to KEY8 RSZR
• Selected parameter name: ASP, LOC SIZE, ROT
P
ERS, BDR, CROP
• X-axis, Y-axis, and Z-axis settings (four edge settings
fo
r crop)
Three-dimensional transform operation mode
The following information is displayed.
• Reference DME channel name: DME1 to DME4
• Selected three-dimensional space: LOCAL, GLB and
SR
C, TRGT
• Selected parameter name: ASP PERS, LOC SIZE, LOC
X
YZ, ROT, AXIS LOC, SPIN, SKEW
• X-axis, Y-axis, and Z-axis settings
Menu parameter operation mode
“MENU” is displayed.
Run control operation mode
The following information is displayed.
• Reference region name
• Register number, register name
• Effect duration
• Current keyframe number, total number of keyframes,
cur
rent timecode
Device/frame memory/clip player operation
mod
e
The following information is displayed.
• Recalled file name (for disk recorder)
• Recalled content name (for frame memory/clip player)
• Current timecode, start point timecode, stop point
t
imecode
Center CTR • When the [CTR] button is
pressed once:
Adjusts the three-dimensional
transform parameters to the
detent positions.
• When the [CTR] button is
pre
ssed twice, or the [CTR]
button is pressed once while
pressing the [SHIFT] button:
Returns the three-dimensional
t
ransform parameters to the
default values.
Function
name
Button
name
Description
X
Y
Z
X
Y
Z
• Restricts the parameters
targ
eted by the operation.
When the [X] button is lit:
Operations on parameter
num
ber 1 using the trackball
are enabled.
When the [Y] button is lit:
Operations on parameter
num
ber 2 using the trackball
are enabled.
When the [Z] button is lit:
Operations on parameter
num
ber 3 using the Z-ring are
enabled.
• When the [X] button, [Y] button,
and
[Z] button are lit green, you
can enter parameter settings
using the numeric keypad
control block.
Fine FINE Switches to fine mode, enabling
fin
e adjustment control of setting
values using the trackball and
Z-ring.
Function
name
Button
name
Description
