3 Display the target page to set.
Select a tab to change the page (Page 1 to Page 14) to
di
splay.
4 Press the target button to set in [Button Assign].
The [Select Function] window appears.
The functions that can be assigned to the cross-point
p
ad button are displayed in the [Select Function]
window.
Select a tab to change the function to display.
When a switcher bank is selected in the [Select
Ba
nk] group
[Row-1 Bus] tab to [Row-4 Bus] tab: Sw
itcher bank
buses to assign to the 1st row to 4th row
[Row-1 Aux] tab to [Row-4 Aux] tab: A
UX buses
to assign to the 1st row to 4th row
[Row-1 Func] tab to [Row-4 Func] tab: Func
tions
to assign to the 1st row to 4th row
[Others] tab: Ot
her functions
[Table/Macro] tab: C
ross-point assign tables and
macro registers
When an AUX bus control block is selected in the
[Sel
ect Bank] group
[Row-3/4 Func] tab: F
unctions to assign to the 3rd
row/4th row
[Others] tab: Ot
her functions
[Macro] tab: Macro
registers
5 Set the button for the function to assign to the on
state.
[Table/Macro] tab or [Macro] tab, table selection
b
uttons/register selection buttons
Set the radio button to the on state, press the input
f
ield, and enter the table number/register number in
the numeric keypad window.
To release the assignment
Set the [No Assign] button to the on state.
6 Press [OK].
To set a page name
Press the [Page Name] button and enter a page name (up
t
o 12 characters) using the keyboard.
To set the page recall function
You can set to display a particular page when a cross-
po
int pad button is pressed.
Buttons configured with a page recall function have a
wh
ite frame around the cross-point pad buttons in the
control panel.
The page recall function can be assigned to buttons in the
cr
oss-point pad to which already have another function
assigned.
1 Press the target button to set in [Jump Page Assign].
The [Select Page] window appears.
2 Set the button for the page to recall to the on state.
To release the page recall function setting
Set the [No Assign] button to the on state.
3 Press [OK].
To release all button assignments
Press the [All Clear] button.
The functions assigned to the buttons on the selected page
and t
he page recall function settings are deleted.
About re-entry signal selection buttons
By default, the following signals are assigned to cross-
poi
nt button numbers 285 to 300.
The re-entry signal selection buttons in the cross-point
pad u
se signals assigned to button numbers 285 to 290
and button numbers 293 to 298.
Note
Function name
a)
Cross-point
button
number
Logical
V/K pair
number
Signal
Row-n Xpt Btn
No
.285
285 213 M/E-1 Out1
Row-n Xpt Btn
No
.286
286 221 M/E-2 Out1
Row-n Xpt Btn
No
.287
287 229 M/E-3 Out1
Row-n Xpt Btn
No
.288
288 205 P/P Out1
Row-n Xpt Btn
No
.289
289 237 M/E-4 Out1
Row-n Xpt Btn
No
.290
290 245 M/E-5 Out1
Row-n Xpt Btn
No
.291
291 284 (black signal)
Row-n Xpt Btn
No
.292
292 284 (black signal)
Row-n Xpt Btn
No
.293
293 217 M/E-1 Out5
Row-n Xpt Btn
No
.294
294 225 M/E-2 Out5
Row-n Xpt Btn
No
.295
295 233 M/E-3 Out5
Row-n Xpt Btn
No
.296
296 209 P/P Out5
Row-n Xpt Btn
No
.297
297 241 M/E-4 Out5
