48
b Display
The display shows the following information.
• Settings of buttons on the 1st row to 4th row (signal
na
me, bus name, register name, or function name
assigned to the button)
• Macro register name of macro attachment assigned to
t
he 1st row to 4th row buttons
When the [SHIFT] button function is set, “SHFT”
app
ears on the display. When the shifted state is selected,
“SHFT” is displayed highlighted, and the button
information also toggles to show the shifted state display.
Display mode
Six types of display mode can be set according to the
i
nformation to display. You can switch the mode using
the [DISP MODE] button assigned to the function button
section. The display can also be subdivided (top and
bottom) to display two pieces of information.
For details, see “Setting the Display” (page 409).
c Cro
ss-point indicators
When lit, these indicate the logical V/K pair color linked
t
o the logical V/K pair assigned to buttons on the 3rd row.
If a signal cannot be selected, because a signal is not
a
ssigned or the inhibit setting is set, the indicator is not lit.
You can disable the cross-point indicators so that they do
no
t turn on.
For details, see “Setting the on/off state of cross-point
indicators” (page 409).
d F
unction button section (assignable buttons)
You can assign functions, such as settings and operations,
o
f the cross-point button rows in the Home > Setup >
Panel > Module > Button Assign menu (19104.21).
For details about assigning buttons, see “Assigning
Control Panel Buttons” (page 402).
3rd row • Selects the background A bus signal when
in key/AUX bus delegation mode or key
bus mode.
• Selects the bus signal assigned by the
d
elegation buttons in the function button
section when in free assign mode.
Selects the utility function when a utility/
s
hotbox bank is assigned using the
delegation buttons in the function button
section.
• Selects the utility 1 bus signal when in
u
tility bus mode.
4th row • Selects the background B bus signal when
i
n key/AUX bus delegation mode or key
bus mode.
• Selects the bus signal assigned by the
d
elegation buttons in the function button
section when in free assign mode.
Selects the utility function when a utility/
s
hotbox bank is assigned using the
delegation buttons in the function button
section.
• Selects the utility 2 bus signal when in
utility bus mode.
Name Description
Function name Button
name
Description
Row-n Bus:
Background A
a) b)
Background B
a) b)
A
B
Assigns background A
and B buses to the 1st
row to 4th row.
n = 1 to 4
Row-n Bus:
Utility 1
a) c)
Utility 2
a) c)
UTIL1
UTIL2
Assigns utility 1 and 2
buses to the 1st row to
4th row.
n = 1 to 4
Row-n Bus:
DME External
a) c)
DME EXT Assigns DME external
video bus to the 1st row
to 4th row.
n = 1 to 4
Row-n Bus:
DME Utility 1
a) c)
DME Utility 2
a) c)
DME UTIL1
DME UTIL2
Assigns DME utility 1
and 2 buses to the 1st
row to 4th row.
n = 1 to 4
Row-n Bus:
Key 1 to Key 8
a) c)
d)
KEY1 to
KEY8
Assigns key 1 to 8
buses to the 1st row to
4th row.
n = 1 to 4
Row-n Bus:
Edit Preview
a) b)
EDIT PVW Assigns edit preview
bus to the 1st row to 4th
row.
n = 1 to 4
Row-n Bus:
FM Source 1
a) b)
FM Source 2
a) b)
FMS1
FMS2
Assigns frame memory
source 1 and 2 buses to
the 1st row to 4th row.
n = 1 to 4
Row-n Bus:
DME1 Video to
DM
E4 Video
a) b)
DME1V to
DME4V
Assigns DME1 to
DME4 video buses to
the 1st row to 4th row.
n = 1 to 4
Row-n Bus:
DME1 Key to
DM
E4 Key
a) b)
DME1K to
DME4K
Assigns DME1 to
DME4 key buses to the
1st row to 4th row.
n = 1 to 4
Row-n Bus:
Utility/Shotbox 1 to
U
tility/Shotbox 10
a)
c)
UTIL/
SBOX1 to
UTIL/
SBOX10
Assigns utility/shotbox
ban
ks 1 to 10 to the 1st
row to 4th row.
n = 1 to 4
Row-n Aux:
Aux 1 to Aux 48
a) b)
AUX1 to
AUX48
Assigns AUX1 to 48
buses to the 1st row to
4th row.
n = 1 to 4
Others:
Row-n Xpt Hold
d)
e)
XPT HOLD Sets cross-point hold
for the buses assigned
to the 1st row to 4th
row.
n = 1 to 4
To Next Page
