Sony MLS-X1 User Manual

49
a) Disabled in key/AUX bus delegation mode.
b) Disabled in key bus mode.
c) 3rd row and 4th row are disabled in key bus mode.
d) Disabled for SL keys.
e) 1st row is disabled in key/AUX bus delegation mode.
f) Disabled in free assign mode.
g) 1st row and 2nd row are disabled in key bus mode.
h) 1st row and 2nd row are disabled in key/AUX bus delegation mode.
Others:
Pre Macro
PRE MCRO Sets macro attachment
in pre-macro mode.
Others:
Post Macro
POST
M
CRO
Sets macro attachment
in post-macro mode.
Others:
Macro Attach
Ena
ble
MCRO
ATTCH
ENBL
Enables macro
at
tachments assigned
to buttons in the
switcher banks.
Others:
Main
MAIN Switches the button
op
eration to the
function on the main
side when in multi
program 2 mode.
Others:
Sub
SUB Switches the button
op
eration to the
function on the sub side
when in multi program 2
mode.
Others:
Display Mode
DISP
MO
DE
Switches the display
mode.
Others:
Row-n Aux Mix
a) b)
AUX MIX Executes an AUX mix
when an AUX bus is
assigned to the 1st row
to 4th row.
n = 1 to 4
Others:
Aux Mix
b) f)
AUX MIX Executes an AUX mix
when an AUX bus is
assigned to the 2nd
row.
Others:
Row-n Key
a) b)
KEY Selects the signal on
the key side in the 1st
row to 4th row.
n = 1 to 4
Others:
Key
b) f)
KEY Selects the signal on
the key side in the 2nd
row.
Others:
Row-n Image
Effe
ct
g) h)
IMAGE Sets the image effect
function on background
A bus or B bus on the
1st row to 4th row.
n = 1 to 4
Others:
Row-n Protect
e)
PROT Inhibits button
operation on the 1st
row to 4th row.
n = 1 to 4
Others:
Utility
a) f)
UTIL Assigns the bus when
in utility bus mode to
the 1st row to 4th row.
Others:
Shift All Bus
SHIFT ALL Switches the cross-
po
int button rows of all
buses to the shifted
state.
Others:
Dual BKGD Bus
f)
DUAL
BKGD BUS
Switches to dual
background bus mode.
Others:
Xpt Inhibit
INHBT SET
Sets/releases inhibit
mode for cross-point
buttons.
Function name Button
name
Description
Others:
Xpt Inhibit All Clear
INHBT
ALLCLR
Releases inhibit mode
for all cross-point
buttons.
Function name Button
name
Description
