Chapter 3 Signal Selection and Transitions
174
Executing a Transition
Frame display mode: Values are shown as from 0 to 999 frames. In this
display mode, a value entered in timecode input mode is converted for
display as a number of frames.
Timecode display mode: Values are shown as timecode values, consisting of
seconds and frames. In this display mode, a value entered in frame input
mode is converted for display as a timecode value. If the value consists of
four or more digits, the last digit is not shown.
Example: A value of 9 seconds 23 frames appears as “9.23” and a value
of 10 seconds 1 frame appears as “10.0.”
Setting the transition rate in the Flexi Pad control block
Notes
In the PGM/PST bank or when using a simple-type transition control block,
you cannot use the Flexi Pad control block to set the transition rate.
1
In the M/E bank Flexi Pad control block, press the [TRANS RATE]
button.
The memory recall section display is now ready to accept the entered
transition rate.
Flexi Pad control block (standard type)
2
Enter the desired transition rate with the numeric keypad.
If required, press the [TC] button to toggle the input mode (frame input or
timecode input).
ENTR button
TRANS RATE button
Memory recall section
TC button
