Chapter 5 Wipes
313
Basic Procedure for Wipe Settings
• The parameter Magnitude determines the size and direction of the spiral.
A value of –100.00 represents the maximum movement in the
counterclockwise direction, and a value of +100.00 represents the maximum
movement in the clockwise direction.
• The parameter Wave Speed determines the speed of the lateral waves.
A value of –100.00 represents the maximum speed to the left, and a value of
+100.00 represents the maximum speed to the right.
You can set the spiral function independently for the main and sub patterns.
1
In the M/E-1 >Wipe menu, select HF5 ‘Main Modify.’
The Main Modify menu appears.
2
Press [Spiral], turning it on.
3
Set the following parameters.
Possible combinations of wipe patterns and modifiers
Yes: Can be used No: Cannot be used
Knob Parameter Adjustment Setting values
1 Magnitude Size and direction of the spiral –100.00 to +100.00
2 Wave Speed Speed of the lateral waves –100.00 to +100.00
Modifiers Type of wipe
Standard Enhanced Rotary Mosaic Random/
diamond dust
Direction Yes Yes Yes Yes Yes
Split Ye s Ye s N o Ye s N o
Edge Yes Yes Yes Yes Yes
Positioner
Ye s
a)
Ye s
b)
Ye s
c)
No No
Rotation Ye s Ye s
Ye s
c)
No No
Aspect ratio
Ye s
d)
Ye s No N o N o
Pattern
replication
Ye s Ye s Ye s
Ye s
e)
No
Pairing
Ye s
f)
Ye s No N o N o
Modulation
(H/V)
Ye s Ye s Ye s N o N o
Modulation
(Fringe)
No
g)
Ye s No N o N o
Spring
No
g)
Ye s No N o N o
To Next Page
