Chapter 7 Frame Memory
396
Still Image Operations
memory are saved automatically when the frame memory selection is
changed.
• For the following signal formats, a field freeze is not possible.
1080PsF/23.976, 1080PsF/24, 1080PsF/25, 1080PsF/29.97, 720P/50,
720P/59.94
Saving a processed freeze image
To save a processed freeze image as a file, in the Still >Composite menu use
the following procedure.
1
Press [Store].
The keyboard window appears.
2
In the keyboard window, enter the file name (maximum eight characters).
3
In the keyboard window press [Enter].
This saves the freeze image as a still image file in memory.
The destination folder is the folder selected in step 4 of “Combining the
background image and input signal” (page 394).
If the entered folder name already exists, a message to confirm overwriting
appears.
Selecting the way in which images are combined
To select the way in which the background image and input signal are
combined (see page 393), use the following procedure.
1
In the <Type> group of the Still >Composite menu, select one of the
following methods of combination.
• Pattern Key: pattern key
• Ext Key: external key
(This can only be selected when the pair mode is enabled. The signal
selected on the frame memory source 2 bus is used as the key signal.)
•Mix: mix
•Nam: non-additive mix
If none of the above is selected, image combination is not carried out.
2
Depending on the selection in step 1, set the following parameters.
• When [Pattern Key] is selected
Knob Parameter Adjustment Setting values
1 Size Size of pattern 0.00 to 100.00
2 Soft Edge softness of pattern 0.00 to 100.00
To Next Page
