Chapter 11 DME Operations
692
DME Special Effect Operations
Bottom Right: Bottom right
All: All four corners
5 Turn the knobs to adjust the position of the corner selected in step 4.
The parameter setting ranges depend on the system’s selected signal
format (SD/HD) and aspect ratio (4:3/16:9) combination, as follows.
• 4:3 mode
a) When the selection for operation is “All,” the Top Left value appears, and the knobs move
all four corners correspondingly.
• 16:9 mode
a) When the selection for operation is “All,” the Top Left value appears, and the knobs move
all four corners correspondingly.
Resetting the corner positions
In the Corner Pinning menu, press [Reset Corner].
Selecting the area used for pinning
When the foreground is cropped, press [Crop Link] to select either of the
following.
On: Use the area of the cropped image for positioning
Off: Use the area of the entire image, including the part hidden by cropping
(shaded in the diagram below) for positioning
Knob Parameter Adjustment Setting values
1 Pos X Movement in x-axis direction –8.00 to
+8.00(SD)
a)
–24.00 to
+24.00(HD)
a)
2 Pos Y Movement in y-axis direction –6.00 to
+6.00(SD)
a)
–18.00 to
+18.00(HD)
a)
Knob Parameter Adjustment Setting values
1 Pos X Movement in x-axis direction –8.00 to
+8.00(SD)
a)
–32.00 to
+32.00(HD)
a)
2 Pos Y Movement in y-axis direction –4.50 to
+4.50(SD)
a)
–18.00 to
+18.00(HD)
a)
