Chapter 2 Menus and Control Panel
106
Names and Functions of Parts of the Control Panel
completion) set for an auto transition,
in frames.
You can set the transition rate using the
numeric keypad control block, Flexi
Pad control block, or menu.
AUTO TRANS (transition) button:
Pressing this button carries out an auto
transition of the set transition rate
(duration). The transition starts
immediately, and the button lights
amber. When the transition completes,
the button goes off.
CUT button: Pressing this button carries
out the transition as a cut (i.e.
instantaneously).
d Wipe direction selection buttons
For details, see “Wipe direction selection
buttons” (page 61).
e TRANS PVW (transition preview)
button
When this button is lit, you can check in
advance the video changes during the
transition, on the preview output from the
M/E or PGM/PST bank.
During the preview, you can use the fader
lever, [AUTO TRANS] button, and [CUT]
button. One of the following functions of
this button can be selected in a Setup menu.
• When the transition completes, the
system returns to the normal mode.
• The transition preview mode is
maintained while this button is pressed.
• Switching is made between the transition
preview mode and normal mode every
time this button is pressed.
f Key status display
For each of keys 1 to 8, the corresponding
ON indicator lights when the key is
inserted. It also shows the priority (1 to 4)
of each key.
g PRIOR (priority) SET button
While this button is held down, you can set
the key priority.
The setting mode when this button is
pressed depends on whether or not the
[KEY PRIOR] button is lit, as follows.
• When the [KEY PRIOR] button is off, the
current key priority is set.
• When the [KEY PRIOR] button is lit, the
key priority after the next transition is set.
Press the [KEY PRIOR] button as required,
to switch between these two modes.
In either mode, hold down the [PRIOR
SET] button, and press the button ([KEY1]
to [KEY8]) corresponding to the key you
want to bring to the front.
Notes
The key priority establishes a separate
priority order within each of the groups of
keys 1 to 4 and keys 5 to 8. You can make
any setting within the groups of keys 1 to 4
or keys 5 to 8, but not for combinations of
keys from different groups. For example, it
is not possible to set a priority sequence of
keys 1, 5, and 2.
For details, see “Setting the Key Priority in
the Transition Control Block” (page 163).
h Independent key transition
execution section
KEY1 TRANS (transition) to KEY8
TRANS (DSK1 TRANS to DSK8
TRANS in the PGM/PST block)
buttons: Press the corresponding one
of these buttons to cut key 1 to key 4 in
or out automatically at the set transition
rate. When the key corresponding to
the button appears in the final program
output, the button lights red, and
otherwise lights amber. During a
transition, the button lights green.
To Next Page
