Chapter 19 Control Panel Setup (Panel)
1102
Overall Control Panel Settings (Config Menu)
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
7
When you have completed the required assignments, press [Set].
Assigning Preview Output to Preview Selection Buttons
It is possible to assign any preview output to a preview selection button.
This applies to the preview selection buttons in the fade-to-black control block
and the downstream key/fade-to-black control block.
For details of these control blocks, see Chapter 2 (Volume 1).
1
In the Panel >Config menu, press [Link/Program Button].
The Link/Program Button menu appears.
2
Press [Fade To Black Module].
The Fade To Black Module menu appears.
On the left of the status area, preview selection buttons (1 to 11) appear.
On the right side a list of signals to be assigned appears.
3
In the button indications on the left, press the button for the assignment.
4
Using any of the following methods, select the signal to be assigned.
• Press directly on the list on the right.
• In the list on the right, press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
5
Press [Set].
This assigns the signal selected in the list to the button.
To cancel an assignment
Select the button, then press [Clear].
This leaves nothing assigned.
Knob Parameter Adjustment Setting values
1 Button Assign Select function to be
assigned to button
1 to maximum value
Knob Parameter Adjustment Setting values
1 Button Button selection 1 and upwards
