Chapter 19 Control Panel Setup (Panel)
1107
Overall Control Panel Settings (Config Menu)
The left side of the status area shows the Top menu selection buttons and
user preference buttons, and the right side shows a list of menus and
actions to be assigned.
3
Using any of the following methods, scroll the display.
• Press the arrow keys.
• Turn the knob.
4
In the button indications on the left, press the button for the assignment.
5
Using any of the following methods, select the menu or action to be
assigned.
• Press directly on the right list.
• Press the arrow keys on the right list to scroll the reverse video cursor.
• Turn the knob.
6
Press [Set] you confirm the setting.
This assigns the menu or action selected in the list to the button.
To cancel an assignment, select the button, then press [Clear].
To return all button assignments to the factory default state, in the Menu
Panel menu, press [Default].
Assigning Functions to the Buttons in the Multifunction
Flexi Pad Control Block
You can assign functions to the buttons in the various parts of the
Multifunction Flexi Pad control block in the following menus.
Mode selection buttons: Multi Function Module menu
Region selection buttons: 10 Key Region Assign menu
Memory recall buttons: Multi Function Module menu
For details of the Multifunction Flexi Pad control block, see “Multifunction
Flexi Pad Control Block” in Chapter 2 (Volume 1).
Knob Parameter Adjustment Setting values
1 Scroll Scroll 1 to 5
Knob Parameter Adjustment Setting values
3 Menu/Action Select the menu or action 1 to 43
To Next Page
