Using the M/E-4 Bank
Using the M/E-4 Bank
Assigning a Button for M/E-4 Selection in the Setup
Menu
• In the factory defaults for this system, M/E-4 is not assigned to buttons on
the control panel.
• To select M/E-4, assign buttons in the Setup menu according to the following
table.
Control
block
Button Menu number Reference in User Guide
“Control Panel Setup (Panel)” and
“Cross-Point Settings (Xpt Assign
Menu)” in Chapter 19 (Volume3)
Cross-point
control block
Reentry buttons 7322.1
7322.5
“Creating Cross-Point Assign Tables”
Engineering Setup >Panel >Xpt Assign
>Table Button Assign menu
Engineering Setup >Panel >Xpt Assign
>Main,V/K Pair Assign menu
Entire
switcher bank
- 7321 “Interchanging the Bank Order or Disabling
Operation”
Engineering Setup >Panel >Config menu
Key control
block
Delegation
buttons
7321.29 “Assigning Functions to Key Control Block
Buttons”
Engineering Setup >Panel >Config >Link/
Program Button >Key Control Module
>Button Assign menu
Device
control block
Region selection
buttons
7321.17 “Assigning Functions to the Device Control
Block”
Engineering Setup >Panel >Config >Link/
Program Button >Joystick/Trackball Module
menu
Numeric
keypad
control block
Region selection
buttons
7321.7 “Assigning a Region to the Region Selection
Buttons in the Numeric Keypad Control Block
or Multifunction Flexi Pad Control Block”
Engineering Setup >Panel >Config >10 Key
Region Assign menu
Fade to black
control block
Preview selection
buttons
7321.13 “Assigning Preview Output to Preview
Selection Buttons”
Engineering Setup >Panel >Config >Link/
Program Button >Fade To Black Module
menu
Menu control
block
Top menu
selection buttons
7321.19 “Assigning Functions to the Menu Control
Block Top Menu and User Preference
Buttons”
Engineering Setup >Panel >Config >Link/
Program Button >Menu Panel menu
