Chapter 7 Frame Memory
397
Still Image Operations
1
In the Frame Memory menu, select VF3 ‘Reposition/Lock’ and HF2
‘Lock.’
The Lock menu appears.
2
In the frame memory selection area, select the FM output. (See page 389.)
3
Press [Lock], turning it on.
This fixes the currently selected frame memory output image.
To release the lock, set [Lock] to off.
Continuously Capturing Still Images (Record)
You can continuously capture (freeze) a sequence of input video frames and
store the sequence of the still images over a specified time interval.
The name of each image recorded in this way consists of a first character string
followed by a second string.
First character string: A common part of name assigned to all the still images
captured in one record operation. This string includes a maximum of four
characters, which can be specified using a menu before carrying out the
capture. The first string is automatically used as the clip name when the
images are treated as a frame memory clip.
Second character string: A four-digit number (0000 or greater), which is
incremented each time a still image is captured.
Notes
When using the record function to continuously capture frames, it is not
possible to use the mask function.
Continuously freezing input images and writing to memory
1
In the Frame Memory menu, select VF1 ‘Still’ and HF4 ‘Animation
Record.’
The Animation Record menu appears.
2
Select the desired frame memory.
For details of the operating procedures, see “Selecting outputs (FM) and
target frame memory” (page 388).
3
To use V/K mode, press [V/K Mode], turning it on.
To Next Page
