Chapter 19 Control Panel Setup (Panel)
1108
Overall Control Panel Settings (Config Menu)
For details of assignment of regions to the region selection buttons, see
“Assigning a Region to the Region Selection Buttons in the Numeric Keypad
Control Block or Multifunction Flexi Pad Control Block” (page 1091).
1
In the Panel >Config menu, press [Link/Program Button].
The Link/Program Button menu appears.
2
Press [Multi Function Module].
The Multi Function Module menu appears.
3
Press one of the following three buttons displayed in the button area.
[Mode Sel Assign] button: To assign a function to the mode selection
buttons
[Eff Edit Assign] button: To assign a function to a button in the memory
recall section for effect editing (when the [EFF] and [EDIT ENBL]
buttons are pressed)
[Macro Edit Assign] button: To assign a function to a button in the
memory recall section for macro editing (when the [MCRO] and
[EDIT ENBL] buttons are pressed)
The left side of the status area shows an image of each button, and the right
side shows a list of menus and actions to be assigned.
4
In the button indications on the left, press the button for the assignment.
5
Using any of the following methods, select the mode or action to be
assigned.
• Press directly on the right list.
• Press the arrow keys on the right list to scroll the reverse video cursor.
• Turn the knob.
a) The following modes and functions can be selected.
• Mode selection buttons
Knob Parameter Adjustment Setting values
3 Button Assign Select the mode or action 1 and upwards
a)
Mode Button indication
Effect EFF
Snapshot SNAP SHOT
Shotbox SHOT BOX
Macro MCRO
Wipe snapshot WIPE
