Chapter 3 Signal Selection and Transitions
149
Signal Selection
PGM/PST Program bus
b)
Program row –
Preset bus
b)
Preset row –
DSK 1 bus DSK 1 row Turn off the dedicated
[SHIFT] button, then turn
off the [DSK3] button.
d)
DSK 2 bus DSK 2 row Turn off the dedicated
[SHIFT] button, then turn
off the [DSK 4] button.
d)
DSK 3 bus DSK 1 row Turn off the dedicated
[SHIFT] button, then turn
on the [DSK 3] button.
d)
DSK 4 bus DSK 2 row Turn off the dedicated
[SHIFT] button, then turn
on the [DSK 4] button.
d)
DSK 5 bus
e)
DSK 1 row Turn on the dedicated
[SHIFT] button, then turn
off the [DSK 3] button.
DSK 6 bus
e)
DSK 2 row Turn on the dedicated
[SHIFT] button, then turn
off the [DSK 4] button.
DSK 7 bus
e)
DSK 1 row Turn on the dedicated
[SHIFT] button, then turn
on the [DSK 3] button.
DSK 8 bus
e)
DSK 2 row Turn on the dedicated
[SHIFT] button, then turn
on the [DSK 4] button.
M/E-1,
M/E-2,
M/E-3,
M/E-4
a)
,
PGM/PST
Utility 1 bus Background A
row
When [UTIL] button mode
is Hold, hold down the
[UTIL] button
Utility 2 bus Background B
row
DME external video bus Key 1 row Hold down the [UTIL]
button
DME utility 1 bus Key 2 row Hold down the [UTIL]
button, and press the
[KEY4] button, turning it
off
DME utility 2 bus Hold down the [UTIL]
button, and press the
[KEY4] button, turning it
on
Auxiliary
bus control
block
c)
AUX1 to AUX48 buses 1st row, 2nd row Turn on the appropriate
buttons in accordance with
the signal assignment
made in the Setup menu.
Frame memory source 1
and frame memory
source 2 buses
Bank Bus name Cross-point
button row
Delegation operation
