Chapter 5 Wipes
307
Basic Procedure for Wipe Settings
• The parameter H Position controls the horizontal position of the pattern.
A negative value moves the pattern to the left, and a positive value moves the
pattern to the right.
• The parameter V Position controls the vertical position of the pattern.
A negative value moves the pattern down, and a positive value moves the
pattern up.
You can set the position independently for the main pattern and sub pattern.
1
In the M/E-1 >Wipe menu, select HF5 ‘Main Modify.’
The Main Modify menu appears.
2
In the <Position> group, press [Position], turning it on, and set the pattern
position.
To return the pattern position to the center of the screen
In the <Position> group, press [Center].
To move the pattern from its current position to the center through
the course of a transition
In the <Position> group, press [Auto Center], turning it on.
To set the wipe position using the trackball or joystick
You can also set the wipe position using the trackball or joystick in the device
control block.
1
In the device control block, press the [M/E1], [M/E2], [M/E3], [M/E4], or
[P/P] button, turning it on.
Notes
The [M/E4] button requires a previous assignment in the Setup menu.
The buttons in the device control block are assigned to the wipe position
setting as follows.
Knob Parameter Adjustment Setting values
1 Position H Horizontal position –200.00 to +200.00
2 Position V Vertical position –200.00 to +200.00
Table 1: Buttons and assigned settings
Button name Setting
MAIN Wipe position for common transition (main pattern)
SUB Wipe position for common transition (sub pattern)
To Next Page
