Chapter 11 DME Operations
718
Global Effect Operations
a) See “Pairwise mixing of Ch1 and Ch2, and Ch3 and Ch4” (page 715).
Automatically setting the priority of overlapping images
To set the system so that the priority of overlapping images is automatically
determined by their position on the z-axis, in the Combiner Priority menu,
press [Auto], turning it on.
Notes
It is not possible to cross images. If an image is rotated, the priority is
determined by the position on the z-axis of the center of the image.
Crossing images from up to four consecutive channels in three
dimensions
Notes
The three-dimensional crossing function is not supported on the MVE-8000A.
1
In the Combiner Priority menu, press [Depth], turning it on.
2
Set the following parameters.
For case “Ch1+Ch2”
For case “Ch1+Ch2+Ch3”
For case “Ch1+Ch2+Ch3+Ch4”
Knobs 1 and 2 set the same parameters as “For case ‘Ch1+Ch2+Ch3’,”
respectively. Knob 3 is additionally effective, which sets the parameter
Soft3 (in the same setting value range as with knobs 1 and 2).
Knob Parameter Adjustment Setting values
1 Mix2 Mix degree for channels
2 and 3
0.00 to 100.00
a)
Knob Parameter Adjustment Setting values
1 Soft Softness of edges of crossed
section
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Soft1 Softness of edges of channel 1
and channel 2 crossed section
0.00 to 100.00
2 Soft2 Softness of edges of channel 2
and channel 3 crossed section
0.00 to 100.00
