Sony MVS -8000X - Page 951

Chapter 16 Macros
951
Macro Attachment Assigning
Block Button
Cross-point control block • Background A row cross-point buttons
• Background B row cross-point buttons
• Key 1 bus cross-point buttons
• Key 2 bus cross-point buttons
• Key 3 bus cross-point buttons
• Key 4 bus cross-point buttons
• Key 5 bus cross-point buttons
a)
• Key 6 bus cross-point buttons
a)
• Key 7 bus cross-point buttons
a)
• Key 8 bus cross-point buttons
a)
• Utility 1 bus cross-point buttons
• Utility 2 bus cross-point buttons
• DME external video bus cross-point buttons
• DME utility 1 bus cross-point buttons
• DME utility 2 bus cross-point buttons
• Memory recall buttons
b)
• Buttons set to “Inhibit”
• Auxiliary bus cross-point row
c)
Auxiliary bus control block • Cross-point button1st row
d)
• Cross-point button 2nd row
d)
Keyframe control block • [RUN], [REWIND] and [FF] buttons
• [NORM], [REV], and [NORM/REV] buttons
Device control block (trackball,
joystick)
The buttons to which the same functions as those of
VTR/disk recorder/Extended VTR/frame memory
clips play, cue, stop, and start tc buttons
Device control block (search
dial)
[PLAY], [CUE], [STOP] and [START TC] buttons
Downstream key control block • [DSK1 ON] to [DSK8 ON] buttons
e) g)
• [KEY1 ON] to [KEY8 ON] buttons
a) e)
• [TAKE] button
e)
• [MIX], [WIPE], [DME], and [CUT] buttons
Transition control block All buttons except [PRIOR SET], [TRANS PVW],
[SHIFT], [ADD], [KF], [MAIN], [SUB], [LIMIT SET],
[K-SS], [K-SS STORE], and key snapshot setting
buttons
Fade to black control block [FTB] button
Downstream key/fade to black
control block
• [DSK1 ON] and [DSK2 ON] buttons
e)
• [DSK3 ON] to [DSK8 ON] buttons
a) e)
• [KEY1 ON] to [KEY8 ON] buttons
a) e)
• [AUTO TRANS] button
e)
• [FTB] button
Utility/shotbox control block Memory recall buttons
Menu control block [PREFS 1] to [PREFS 16] buttons
Independent key transition
control block (simple type)
f)
• [KEY1 ON] to [KEY8 ON] buttons
e) g)
• [DSK1 ON] to [DSK8 ON] buttons
e) g)
• [TAKE] button
e)
• [MIX], [WIPE], [DME], and [CUT] buttons
