50 Installation and Setup
2005995 Rev O – 210712
Straightshooter Mode
Printhead bottom is 2” (50.8 mm)
higher than Ink Pan top
Solvent Printhead with Bag System
Ink Pan
Printhead
Printhead
Printhead
Printhead Nozzle Face is 2” (50.8 mm)
higher than Ink Pan top
Printhead’s lowest side is 2” (50.8 mm)
higher than Ink Pan top
Ink Pan
Ink Pan
Downshooter Mode
Sideshooter Mode
2” (50.8 mm)
2” (50.8 mm)
2” (50.8 mm)
