64 Installation and Setup
2005995 Rev O – 210712
5. Fold a non-abrasive, lint-free wipe and place it below the front of the Nozzle Face to
catch any excess ink.
6. On the rear of the Ink Reservoir, press the Priming Bulb repeatedly until ink exits the
Drain Tube and the Nozzle Face. A slow drip out of the Printhead is required for an
effective purge. Continue to press the Priming Bulb until ink comes out of the Purge
Tube without air bubbles.
7. Replace the Cap on the Purge Tube. This seal must be tight for the printer to
function.
Purge Tube
(uncapped)
Printhead
Preparing to Prime the Printhead
Nonabrasive
Lint-Free Wipe
Ink Line
IN
Waste Ink
Receptable
Ink
Cartridge
Ink
Reservoir
Priming
Bulb
Pressing the Priming Bulb
To Next Page
