Installation and Setup 65
2005995 Rev O – 210712
8. Fold a non-abrasive, lint-free wipe and hold it against the lower part of the Nozzle
Face.
9. Press the Priming Bulb repeatedly until bubble-free ink comes out of all the Printhead
Nozzles.
10. When finished purging, gently wipe excess ink from the Nozzle Face.
The Printhead is now commissioned and ready to print.
Capping the Purge Tube
Purge Tube
(capped)
To Next Page
