6-9
Routine Maintenance Operator Manual 920011-649
See Figures 6-3 and 6-4.
Wearing appropriate Personal Protective Equipment (PPE), replace
Bag-in-a-Box container as follows:
1. Open Bag-in-a-Box compartment door. Raise locking plate to
release feed line connector.
2. Pull out feed line connector of identified container (about
25 mm [1”]).
3. Remove empty Bag-in-a-Box container. Dispose as follows:
a. Open box and remove bag.
b. Cut an opening in one of bottom corners of bag.
c. Rinse bag three times under running water (inside and
outside).
d. Dispose of bag in regular trash.
e. Box may be recycled if desired or thrown into regular trash.
4. Remove drip tray fitting.
5. Wash fitting under running water and dry with a lint free cloth.
6. To open new Bag-in-a-Box container, press along perforated
line.
NOTE: Do not tear off and remove the perforated cardboard flap.
7. Hold Bag-in-a-Box container upside down and pull out snap-on
closure.
8. Cardboard flap must be inserted in exterior groove of snap-on
closure (see Figure 6-4, Detail B).
9. Insert drip tray fitting into exterior groove of snap-on closure (see
Figure 6-4, Detail B).
NOTE: Drip tray fitting and cardboard flap must be inserted in the
exterior groove.
10. Place Bag-in-a-Box container on proper shelf (see Figure 6-3).
11. Pivot feed-line connector and connect it to snap-on-closure.
12. Pivot locking plate over feed line connector and secure plate
in feed line connector groove and locking pin groove (see
Figure 6-4, Detail C).
13. Close Bag-in-a-Box compartment door.
14. Press START touch pad to resume cycle. Display shows:
15. Once cycle is in progress, Klenzyme or CIP 200 cleaner injection
pump automatically injects a preprogrammed amount of cleaner
in solution.
OPERATING
MMM M
IN
WARNING – PERSONAL INJURY
AND/OR EQUIPMENT DAMAGE
HAZARD: Bag-in-a-Box
compartment door can support
a maximum of 4.5 kg (10 lb). Do
not place heavy objects on Bag-
in-a-Box compartment door.
WARNING – CHEMICAL BURN
AND/OR EYE INJURY HAZARD:
CIP 200 Acid-Based Process
and Research Cleaner is
corrosive and can cause
adverse effects to exposed
tissues. Do not get in eyes,
on skin or swallow. Read and
follow all precautions and
instructions on cleaner label
and in Safety Data Sheet (SDS)
prior to handling CIP 200 Acid-
Based Process and Research
Cleaner Bag-in-a-Box container
or servicing cleaner injection
pump. Wear appropriate
Personal Protective Equipment
(PPE) whenever handling
cleaner or servicing cleaner
injection pump and lines.
WARNING – EYE INJURY
HAZARD: Klenzyme Enzymatic
Presoak and Cleaner
concentrate may cause serious
damage to eyes. Product may
cause skin irritation. Do not
get on skin or in eyes. Read
and follow all precautions and
instructions on cleaner label
and in Safety Data Sheet (SDS)
prior to handling Klenzyme
Bag-in-a-Box container or
servicing cleaner injection
pump. Wear appropriate
Personal Protective Equipment
(PPE) whenever handling
cleaner or servicing cleaner
injection pump and lines.
