Steris Reliance EPS Endoscope Processing System - Figure 4-20. Leak Test Hoses Connections Flowchart

4-21
Processing Instructions Operator Manual 920011-649
DETECTION BY CONTROL
Leak Test Hose(s) Connected ?
Ye s
No: “Audible Signal” *
▼
▼▼
Stop Touch PadIgnore
▼
▼
▼
▼
Draining
Cancel
Open Door
▼
No Further Action Required
▼
▼
▼
▼ ▼
▼
▼
Go to Step 1 of
S ECTION 4.4.4,
O
PTIONAL A UTOMATED L EAK T EST -
A
UDIBLE S IGNAL
No Leak Test
“None” Printout
Leak Test
“P
ass” or “Fail”
Printout **
Resume
Connect Hose(s)
▼
Do Not Acknowledge
Audible Signal
▼
▼
▼
No Leak Test
“None” Printout
Start New Cycle
* Possible cause:
• Hose connected to endoscope b
ut not connected to Reliance EPS Processor.
** If automated leak test fails, an alarm is triggered.
Figure 4-20. Leak Test Hoses Connections Flowchart
