4-35
Processing Instructions Operator Manual 920011-649
4.8.5 Monitoring Cycle During cycle, information is printed about cycle in progress. See
Figures 4-24 and 4-25 for typical sample printout.
At any time during cycle, operator can display temperature and
pressure inside control handle boots by pressing touch pad of cycle
in process (SINGLE or DOUBLE).
1. Press once, display shows, for example:
2. Press a second time, display shows, for example:
Fir
st line shows current water temperature in °C or °F,
Second line shows current air purge temperature in °C or °F.
3. Press a third time, display shows:
A = Pressure in control handle boot "A", in kPa or psig.
B = Pressure in control handle boot "B", in kPa or psig.
NOTE: If an error message is displayed or an abnormal situation
occurs at any time during cycle, refer to S
ECTION 7,
TROUBLESHOOTING, for possible causes and solutions.
SINGLE
WASH
WATER: XXX.X C
AIR: XXX.X C
[A] : XXX.X KPA
[B] : XXX.X KPA
or
Cycle In Process
Segment In Process
WARNING – PERSONAL INJURY
AND/OR EQUIPMENT DAMAGE
HAZARD: In an emergency,
stop cycle by pressing STOP
touch pad twice to abort cycle.
Wait for processor to complete
Abort sequence. Wear
appropriate Personal Protective
Equipment (PPE) when
reaching into chamber.
WARNING – INEFFECTIVE
PROCESS HAZARD: Correct
function of the system is only
ensured after any diagnosed
errors have been found,
corrected and a successful
processing cycle has been
completed.
