4-38
920011-649 Operator Manual Processing Instructions
4.8.6 Completing Cycle 1. After four minutes of air purge (adjustable from 4 to 30 minutes in
Supervisor mode), buzzer sounds and display shows:
It is now possible to unload processor or let air purge phase
continue. If door is not opened once set air purge time has
elapsed, air purge continues for up to a total of 60 minutes.
2. Press STOP touch pad to stop air purge and unload processor.
Display shows:
and printer records:
===========================
STOP PRESSED HH:MM:SS XM
SAFETY DOOR LOCK HH:MM:SS XM
DISENGAGED
===========================
Processor cools for 30 seconds. Then display shows:
Processor drains for 20 seconds.
3. After draining is completed, buzzer sounds and display shows:
4. Printer records complete cycle printout (see Figures 4-24 and
4-25 to view an example of a typical printout).
If EXTENDED PRINTOUT feature is enabled in Miscellaneous
menu of Supervisor mode, there is additional space on
printout to allow operator to write down additional information
(refer to S
ECTION 5.2.3, SETTING MISCELLANEOUS VALUES, for
setting procedure and see Figures 4-24 and 4-25 to view an
example of an extended printout).
If MULTIPLE PRINTOUTS feature is enabled in Miscellaneous
menu of Supervisor mode, printer automatically generates
number of printouts requested in Supervisor mode for each
endoscope (refer to S
ECTION 5.2.3, SETTING MISCELLANEOUS
VALUES, for setting procedure).
NOTE: If a DOUBLE endoscope processing cycle is running, the
number of printouts doubles.
CYCLE COMPLETE
PRESS STOP
COOLING
PLEASE WAIT
DRAINING
PLEASE WAIT
CYCLE COMPLETE
READY TO UNLOAD
