Customer Replaceable Units Right and Left Side Oven Blowers
Page 176
© Copyright 2020 Stratasys. All rights reserved.
Right and Left Side Oven Blowers
Required Tools
• 2.5 mm hex wrench
• 3 mm hex wrench
Removing the Oven Blower
1. Power OFF the printer. See “Powering OFF the Printer” (page 159).
2. Remove the rear panel. See “
Removing the Rear Panel” (page 161).
3. Remove the side panels. See “
Removing the Side Panels” (page 162).
4. Disconnect the oven blower motor connector from the I/O board (J39 - right blower, J37 -
l
eft blower).
5. Using a 3 mm hex wrench, remove the mounting screws (5) that secure the blower
a
ssembly to the oven frame, see Figure 30 (page 177).
Note:
Take note of the wire routing configuration for ease of installation.
To Next Page
