Customer Replaceable Units Touchscreen Display
Page 173
© Copyright 2020 Stratasys. All rights reserved.
Installing the Head Ribbon Cables
1. Install the rear ribbon cable bracket to cutouts at the back, top of the printer frame. See
Figure 26 (page 172).
2. Using a 3 mm hex wrench install the mounting screws (3) to fasten the front ribbon cable
b
racket to the back of the toggle assembly. See Figure 25 (page 171).
3. Connect the rear head ribbon cable connectors (2) to the I/O board (J6 and J7). See
F
igure 24 (page 171).
4. Connect the front head ribbon cable connectors (2) to the material and support heads. See
F
igure 24 (page 171).
5. Install the rear panel. See “
Installing the Rear Panel” (page 161).
6. Close the top cover.
Touchscreen Display
Required Tools
• T8 Torx wrench (included with spare part)
Removing the Touchscreen Display
Caution:
The connectors and cables of the touchscreen display are fragile. Excessive force
may cause damage to connector pins or wiring.
