Objet1000 Plus User Guide 6 Operating and Maintaining the Objet1000 Plus 3DPrinter
DOC-06810 Rev.B 6-69
Warning: Broken UV lamp hazard
UVlampscontainmercury.Dealwithbrokenlampswithcaution.
l Ventilatetheroomthoroughly.
l Useprotectivegloveswhencollectingmercuryandlampcomponents.
l Removespilledmercurywithamethodthatpreventsthegenerationof
mercuryvapor,suchasasyringe,packingtapeorpaper.
l Placethebrokenlamp,mercuryandcontaminatedmaterialsinanair-tight,
non-metalliccontainer.
10.InsertthenewUVlamp/reflectorunitintothehousing,nexttotheprint
block.
Figure6-108PrintblockandUVlampassembly,showingcorrect
placementofblackstrip
11.ReplacetheUVlampcoverbyinsertingitintotheslotonthebottomof
thehousing,andtightenthesecuringscrewontop.
Figure6-109ReplacingtheUVlampcover
