Objet1000 Plus User Guide 6 Operating and Maintaining the Objet1000 Plus 3DPrinter
DOC-06810 Rev.B 6-68
6. LoosenthescrewsecuringtheUVlampcover(A),andpullthecoverup
(B),thenout(C).
Figure6-106RemovingtheUVlampcover
7. PulltheUVlampreflectoroutoftheprintblock.
Figure6-107RemovingtheUVlampreflector
8. InspectthenewUVlampreflector,andmakesurethatablackstripis
attachedtotheinsideofit.Ifnot,installone—onthesideofthereflector
opposite(notnextto)theprintblock.
Note: ExtrablackstripsareincludedintheprinterStart-UpKit.Ifnecessary,
youcanremovetheblackstripfromtheoldreflectorandinstallitinthenew
reflector(aslongastheblackpainthasnotfaded).
9. DiscardtheoldUVreflectorandlamp.
DisposeoftheusedUVlampinaccordancewithenvironmentalandsafety
requirements.
