Objet1000 Plus User Guide 5 Using Objet Studio
DOC-06810 Rev.B 5-37
Toresetallofthevaluesinthedialogbox:
➢ ClickReset.
Note: Theobjectdoesnotchange.Anychangespreviouslyappliedremain.
ToundoallchangesmadewiththeTransformdialogbox:
➢ ClickCancelActions.
AfterclosingtheTransformdialogbox,clickingUndo(ontheModel Settings
ribbonorfromtheEditmenu)cancelsallchangesmadewiththedialogbox.
Changing an
Object’s
Orientation
Thereareseveralmethodsforchangingtheorientationofobjectsonthe
buildtray.
Torotateanobject:
➢ SelecttheobjectandusetheObjectmenuoptions(seealso"Repositioning
Objects"onpage5-35).
Tore-alignanobject’splane:
1. OntheTray SettingsorModel Settingsribbon—
a. ClicktheiconintheSelectiongroup: or .
b. Ontheflyouttoolbar,clicktheSelect Planeicon:
or—
FromtheToolsmenu,selectPlaneAlignment>SelectPlane.
