Objet1000 Plus User Guide 5 Using Objet Studio
DOC-06810 Rev.B 5-39
Tocancelplaneselectionafterre-aligningobjectsonthebuildtray:
➢ OntheTray SettingsorModel Settingsribbon—
a. ClicktheiconintheSelectiongroup: or .
b. Ontheflyouttoolbar,clicktheSelect ElementorSelect Group icon:
or—
➢ FromtheToolsmenu,selectPlaneAlignment>SelectPlane.
Toflipanobject180degreesonanyaxis:
1. Selecttheobject.
2. FromtheObjectmenu,selectFlip>FlipX/FlipY/FlipZ.
Tomakeprecisechangestotheobject’sorientationonanyaxis:
1. Selecttheobject.
2. DisplaytheTransformdialogbox(seeFigure5-44onpage5-36).
3. ChangetheRotateparametersforeachaxis.
