Power Unit Mechanical: 1D-14
21) Remove the side cover seal (21).
22) Disconnect shift position sensor lead wire connector
(22).
Disconnect neutral switch lead wire connector (23).
Remove the bolt and lead wire clamp plate (24).
23) Remove the cotter pin (25) and washer (26).
Remove the clutch lever link (27) from the clutch link
holder assembly.
24) Remove the two bolts and clutch link holder
assembly (28).
25) Disconnect the water return hose (29), then remove
the thermostat cover (30) and thermostat.
26) Remove the two bolts and breather pipe (31).
I9J011140143-01
I9J011140144-01
I9J011140145-01
I9J011140146-03
I9J011140147-01
I9J011140148-01
