148 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010
Appendix A Alarms, Events and SNMP Traps
SNMP Traps
SNMP Traps
The MIB for TimeCreator 1000 v1.2 has MIB var bindings for all Symmetricom
specific SNMP traps, as shown in Table A-4 below:
See Figure A-1, Figure A-2, and Figure A-3 for details about other relevant MIB
table entries.
Table A-4. MIB Var Bindings for Symmetricom- specific Traps
trapID A unique string assigned to each trap
trapAID1 integer, trap AIDs
trapAID2 integer, trap AIDs
trapState The TimeCreator 1000 provides set and clear trap messages to
notify you when certain conditions are exceeding the
user-specified levels (when traps are set) and when certain
conditions return to within the user-specified levels (when traps
are cleared). Traps also indicate hardware and signal status.
These are integer values, where:
clear (1) - the condition for this trap has been cleared,
set (2) - the trap condition has been raised
trapSeverity A 32 bit-wise value:
minor (1), major (2), critical (3), clear (4), nonalarm (5)
trapTimestamp The time when the trap was generated
trapDescription A string description for the trap
trapValue String, trap value
Note: Users need to load 2 mib files into their MIB browser:
 symm-smi.mib
 TC1000.my
The symm-smi.mib file must be loaded first before TC1000.my file.
(The “TC1000.my” file was originally named
“TC1000.mib” in v1.1
and v1.0 of TimeCreator 1000.)
