284 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010
Appendix D Specifications and Factory Defaults
Specifications
Specifications
This section provides the specifications for the TimeCreator 1000 components and
input and output signals.
Mechanical
Environmental
Table D-1. TimeCreator 1000 Mechanical Specifications
Parameter Description
Mounting 19 in. Rack
Rack Mounting
Positions
Front mounting location, unit protrudes 0.75 in.
(4.445 cm)
Mid-point mounting location, unit protrudes 6.33 in.
(16.08 cm)
Width 17.25 in. (43.82 cm)
Height 1.75 in. (4.45 cm)
Depth 19.9 in. (50.5 cm)
Weight 11 lb. (5 kg) fully loaded 7 lb. (3.2 kg) empty
Table D-2. TimeCreator 1000 Environmental Specifications
Parameter Description
Operating Temperature 0 to 40C, 32 to 104 F
Storage Temperature –25 to 70 C, –13 to 158 F
Operating Humidity 10% to 90% RH non-condensing
Storage Humidity 5% to 90% RH non-condensing
