38 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010
Chapter 2 Engineering and Ordering Procedures
Overview
Overview
The TimeCreator 1000 can operate in either a basic configuration, or in a redundant
configuration in one shelf. Basic configuration consists of the following components:
 1 Shelf
 1 IMC module
 1 AC or DC power module
 1 12-port or 8-port IOC module
Redundant configuration consists of the following components:
 1 Shelf
 1 IMC module
 2 AC or DC power modules
 2 12-port or 2 8-port IOC modules
TimeCreator 1000 Part Numbers
System Configurations
This section provides part numbers and descriptions for the various system
configurations and parts available for the TimeCreator 1000. Table 2-1 provides a
list of common configurations and Table 2-3 lists the shelf component and
accessory part numbers.
Note: When operating in basic configuration, blank panels are
available to cover the vacant module slots in the shelf.
Table 2-1. Common Configurations
System Configuration Part Number
TimeCreator 1000 No Redundancy With NA AC Power - see Table 2-5 990-93101-01
TimeCreator 1000 - NA AC Power (1 SH, 1 IMC, 2 IOC, 2 AC) - see Table 2-6 990-93105-01
TimeCreator 1000 - NA AC Power, 8port IOC (1 SH, 1 IMC, 2 IOC-8 port, 2 AC) -
see Table 2-7
990-93105-02
TimeCreator 1000 - DC Power (1 SH, 1 IMC, 2 IOC, 2 DC) - see Table 2-8 990-93106-01
