097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 285
Appendix D Specifications and Factory Defaults
Specifications
Power
Serial Port
Table D-3. TimeCreator 1000 Power Specifications
Parameter Description
AC Input Power 100-240 V AC at 50/60 Hz.
AC Power Fuse 2 A (2 each)
AC Power 40 W
DC Input Power –36 V DC to –72 V DC
–48 V DC, 2.7 A (maximum)
Either positive or negative ground
DC Recommended
Battery Feed Fuse
3 A
DC Power 40 W
Table D-4. Serial Port Specifications
Item Description
Connector Type 9-pin, female D connector
Connector Label Craft
Interface RS-232
Baud Rate 9600 Kbps (57600 is supported only in the IMC rev H
version 1.00.13 or below)
Data Bits 8
Parity Bit None
Stop Bits 1
Flow Control None
