Symmetricom TimeCreator 1000 User Manual

40 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010
Chapter 2 Engineering and Ordering Procedures
TimeCreator 1000 Part Numbers
Two-Way GPS Antenna
Table 2-4 lists the parts available for the GPS antenna.
Common Configuration Parts Lists
The following tables list the items shipped with each common system configuration.
In addition, Table 2-13 provides a list of items shipped with the GPS Antenna Kit,
and Table 2-14 provides the NTP option license part number.
IOC Module Slot Blank Panel 090-93122-01
Power Module Slot Blank Panel 090-93142-01
TimeCreator 8 port to 12 port
IOC Upgrade kit
990-93121-99
Table 2-4. GPS Parts and Accessories
Part Number Description
990-93500-01
1
Note:
1
Kit includes GPS antenna, mounting hardware, and lightning
suppressor. Order antenna cables separately
Two Way Antenna Kit
090-58545-01 Two Way GPS Antenna (spare)
043-00018-01 Lightning suppressor (spare)
060-58545-01 RG-58 cable, 3 m (10 ft.)
060-58545-02 RG-58 cable, 6 m (20 ft.)
060-58545-05 RG-58 cable, 15 m (50 ft.)
060-58545-10 RG-58 cable, 30 m (100 ft.)
060-58545-20 RG-58 cable, 60 m (200 ft.)
060-58545-30 RG-58 cable, 90 m (300 ft.)
060-58545-50 RG-58 cable, 150 m (500 ft.)
154-00023-01 Crimp tool for RG-58 cable
371-001 TNC connectors for RG-58 cable
Table 2-3. Component Part Numbers
Item Part Number
