Symmetricom TimeCreator 1000 User Manual

58 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010
Chapter 3 Installing the TimeCreator 1000
Making Ground and Power Connections
Figure 3-5. TimeCreator 1000 DC Power Module
AC Power
1. Ensure the power source is turned off.
2. Connect the power cord to the power connector on the 120V-220V AC Power
Module.
3. Connect the power cord to the power source.
Figure 3-6. TimeCreator 1000 AC Power Module
Note: The AC power socket contains two 2 amp fuses: one in line
and one spare.
Warning: To avoid possible damage to equipment, you must provide
power source protective fusing as part of the installation.
