Symmetricom TimeCreator 1000 User Manual

286 TimeCreator 1000 User’s Guide 097-93100-01 Revision C – February, 2010
Appendix D Specifications and Factory Defaults
Specifications
LAN Port
Input Signals
Output Signals
Table D-5. LAN Port Specifications
Connector Description
MGMT RJ-45 (10Base-T/100 Base-T) - Supports two telnet
sessions
and two SSH sessions over TCP/IP.
NTP RJ-45 (10Base-T/100 Base-T) - Supports NTP clients
that comply with RFC 1305.
Table D-6. Input Signal Specifications
Parameter Specification
GPS
Requirement Proprietary Rooftop Antenna (see Roof Antenna
specification in Table D-8)
Interface TNC connector
DTI
Termination Impedance 100 ohms
Amplitude 2.2Vpp to 2.8Vpp
Data Rate 5.12 Mbps
Table D-7. Output Signal Specifications
Parameter Specification
Termination Impedance 100
Amplitude 2.2Vpp to 2.8Vpp
Data Rate 5.12 Mbps
