Chapter 3 Installing the TimeCreator 1000
Applying Power to the TimeCreator 1000
DTI Links
A/11 - B/12 DTI
Client State
Off Disabled, or Enabled and qualified as reference input
Amber Enabled and not qualified as reference input
A/11 - B/12 DTI
Client Connection
Status
Off Disabled or not connected to DTI Server
Green Connected to DTI Server
A/11 - B/12 DTI
Server State
Off Disabled, or client operating normally
Amber 1. Enabled, client indicates Warm-up, Free-run,
Holdover, or Acquire states
2. In Test Mode, the DTI Output State LED and DTI
Server Port Connectivity Status LED alternate
being ON and OFF
A/11 - B/12 DTI
Server Connection
Status
Off Disabled or not connected to DTI client
Green 1. Connected to DTI client
2. In Test Mode, the DTI Server Port State LED and
DTI Server Port Connectivity Status LED alternate
being ON and OFF
1 - 10
DTI Server State
Off Disabled, or client operating normally
Amber 1. Enabled, client indicates Warm-up, Free-run,
Holdover, or Acquire states
2. In Test Mode, the DTI Output State LED and DTI
Server Port Connectivity Status LED alternate
being ON and OFF
1 - 10
DTI Server
Connection Status
Off Disabled or not connected to DTI client
Green 1. Connected to DTI client
2. In Test Mode, the DTI Server Port State LED and
DTI Server Port Connectivity Status LED alternate
being ON and OFF
Table 3-5. Module LED Descriptions (Continued)
LED Color Description
