VAP416 Installation & Operation Manual
TD-1/07-004
75 / 81
ADR.
FUNCTION
VALUE
DEFAULT
VALUE
DETAILS
INST.
VALUE
05 01
05 02
05 03
05 04
CMS Phone
CMS 1
CMS 2
Secondary number of CMS 1
Secondary number of CMS 2
Maximum 15 digit phone number (including dialing tone if
the number will be dialed from extension number).
Press 0 long and √ to delete the number.
CMS dialing is enabled (1.option in 50 01) automatically
when phone number is entered.
Free
IP
Page:39
06 01
06 02
:
06 07
06 08
User phone Numbers
User Phone 1
User Phone 2
:
User Phone 7
User Phone 8
Maximum 15 digit phone number (including dialing tone if
the number will be dialed from extension number).
Press 0 long and √ to delete the number.
When the telephone number is entered, user phone number
dialer (2 option in the address of 50 01) actives
automatically.
Free
IP,MP
Page:40
07 01
07 02
:
07 29
User Codes
User Code 1
User Code 2
:
User Code 29
4 digit code
If "0000" is entered, that user becomes disabled.
Free
MP
Page:41
07 30
Guest Code
4 digit code
If "0000" is entered, that user becomes disabled.
Free
MP
Page:41
07 31
Duress Code
4 digit code
If "0000" is entered, that user becomes disabled.
Free
MP
Page:42
07 32
PC Connection Code
4 digit code
If "0000" is entered, that user becomes disabled.
7777
MP
Page:42
10 01
Panel Settings
1.option=Smart partition technology enable/disable
2.option=Quick arm enable/disable
3.option=Auto siren test enable/disable
4.option=Arm/disarm from foreign keypad enable/disable
5.option=Extendable exit delay enable/disable
6.option=Double hit enable/disable
7.option=Daylight saving enable/disable
2,5,7
Selected
IP
Page:42
For SPT:30
10 02
Output Types
1.option=SRN NC=on, NO=off
2.option=PGM1 NC=on, NO=off
3.option=PGM2 NC=on, NO=off
4.option=PGM3 NC=on, NO=off
All NO
IP
Page:43
10 03
Automatic Bypassed
Partitions
1.option=A Partition
2.option=B Partition
3.option=C Partition
4.option=D Partition
-
IP
Page:44
For SPT:30
10 04
Reset Type
1.option=Reset codes
2.option=Reset panel settings
-
IP,MP
Page:44
10 06
Reset Enable/Disable
1.option=Resetting codes enable/disable
2.option=Resetting panel settings enable/disable
1,2
Selected
IP
Page:44
10 08
AC Fail Calling Delay
0...60 minutes
15
IP
Page:45
10 09
Double Hit or Cross Zone
Timer
0...255 seconds
Note: If "0" is entered, cross zone feature is closed.
60
IP
Page:45
11 01
Siren Partitions
1.option=A Partition
2.option=B Partition
3.option=C Partition
4.option=D Partition
All
Selected
IP
Page:45
For SPT:30
11 02
Siren Cut off Time
2...255 minutes
3 minutes
IP
Page:46
12 01
Automatic Arm Partitions
1.option=A Partition
2.option=B Partition Note: Automatic Arm is disabled if no
3.option=C Partition partition is selected
4.option=D Partition
Disabled
IP
Page:46
For SPT:30
12 02
Automatic Arm Days
1.option=Monday 5.option=Friday
2.option=Tuesday 6.option=Saturday
3.option=Wednesday 7.option=Sunday
4.option=Thursday
All
Selected
IP,MP
Page:47
12 03
Automatic Arm Time
HH MM HH=hour, MM=minute
00:00
IP,MP
Page:47
12 04
Automatic Disarm Partitions
1.option=A Partition
2.option=B Partition Note: Automatic disarm is disabled if
3.option=C Partition no partition is selected
4.option=D Partition
Disabled
IP
Page:47
For SPT:30
12 05
Automatic Disarm Days
1.option=Monday 5.option=Friday
2.option=Tuesday 6.option=Saturday
3.option=Wednesday 7.option=Sunday
4.option=Thursday
All
Selected
IP,MP
Page:48
12 06
Automatic Disarm Time
HH MM HH=hour, MM=minute
00:00
IP,MP
Page:48
12 07
Arm Partitions on no Activity
1.option=A Partition
2.option=B Partition Note: Arm no activity is disabled if
3.option=C Partition no partition is selected
4.option=D Partition
Disabled
IP
Page:48
For SPT:30
