VAP416 Installation & Operation Manual
TD-1/07-004
76 / 81
ADR.
FUNCTION
VALUE
DEFAULT
VALUE
DETAILS
INST.
VALUE
12 08
No Activity Time
5...255 minutes
30 minute
IP
Page:49
13 01
13 03
13 05
13 07
13 09
13 11
13 13
13 15
PGM1 Usage Type
PGM2 Usage Type
PGM3 Usage Type
PGM4 Usage Type(*)
PGM5 Usage Type(*)
PGM6 Usage Type(*)
PGM7 Usage Type(*)
PGM8 Usage Type(*)
0=Free
1=PGM is active while selected zones are active
2=PGM is active while selected zones are active
3=PGM is activated when selected partitions are armed
4=Fire siren
5=PGM resets fire detector when fire alarm is ended
6=Siren
7=PGM is active on selected troubles
8=PGM controls magnetic door (Access Control)
9=Timer controls PGM (**)
10=Random PGM on/off
11=On arm
12=On disarm
13=Control with remote control button
14=Alarm type indicator
* VAP416 has 3 onboard PGM outputs. The PGM number
can be increased to 8 PGMs by using TRM904 module.
** This option is valid for the first 4 PGM's.
0
IP
Page:49
For SPT:30
13 02
13 04
13 06
13 08
13 10
13 12
13 14
13 16
PGM1 Parameter
PGM2 Parameter
PGM3 Parameter
PGM4 Parameter(*)
PGM5 Parameter(*)
PGM6 Parameter(*)
PGM7 Parameter(*)
PGM8 Parameter(*)
0...255
Note: The meaning of PGM can be changed according to
usage.
* VAP416 has 3 onboard PGM outputs. The PGM number
can be increased to 8 PGMs by using TRM904 module.
0
IP
Page:51
14 01
14 04
14 07
14 10
Timer1 Setting
Timer2 Setting
Timer3 Setting
Timer4 Setting
1.option=PGM1 Control enable/disable
2.option=PGM1 State (on/off)
3.option=PGM2 Control enable/disable
4.option=PGM2 State (on/off)
5.option=PGM3 Control enable/disable
6.option=PGM3 State (on/off)
7.option=PGM4 Control enable/disable(*)
8.option=PGM4 State (on/off)
* VAP416 has 3 onboard PGM outputs. The PGM number
can be increased to 8 PGMs by using TRM904 module.
-
IP,MP
Page:51
14 02
14 05
14 08
14 11
Timer1 Days
Timer2 Days
Timer3 Days
Timer4 Days
1.option=Monday 5.option=Friday
2.option=Tuesday 6.option=Saturday
3.option=Wednesday 7.option=Sunday
4.option=Thursday
All
Selected
IP,MP
Page:52
14 03
14 06
14 09
14 12
Time of Timer1
Time of Timer2
Time of Timer3
Time of Timer4
HH MM HH=hour, MM=minute
00:00
IP,MP
Page:52
15 01
Remote Control Setting
1.option=Phone Remote Control enable/disable
2.option=PC Remote Control enable/disable
Nothing
Selected
IP,MP
Page:52
15 02
Answer Ring Count
0...20 times
Note: If "0" is selected, double call feature is enabled.
5
IP,MP
Page:53
16 01
KEY Settings
2.option=Continues=on, Pulse Contact=off
Pulse
IP
Page:54
16 02
KEY Partitions
1.option=A Partition
2.option=B Partition
3.option=C Partition
4.option=D Partition
All
Selected
IP
Page:54
For SPT:30
20 01
20 02
:
20 16
:
20 32
Zone Wiring
Z1
Z2
:
Z16
:
Z32
1.option=NC=on, NO=off
2.option
3.option
No resistor
off
off
Single end of line resis
on
off
Double end of line resis
off
on
Double zone
on
on
4.option=Zone enable/disable
If Z17,...Z32 are activated by doubled zone, choice 2 and 3
do not need any setting.
Note: Zone doubling feature can’t be used together with
zone expansion module.
1, 4
Selected
IP
Page:55
21 01
21 02
:
21 16
:
21 32
Zone Partitions
Z1
Z2
:
Z16
:
Z32
1.option=A Partition
2.option=B Partition
3.option=C Partition
4.option=D Partition
Note: The settings are not considered at SPT.
A
IP
Page:55
For SPT:30
