VAP416 Installation & Operation Manual
TD-1/07-004
77 / 81
ADR.
FUNCTION
VALUE
DEFAULT
VALUE
DETAILS
INST.
VALUE
22 01
22 02
:
22 16
:
22 32
Zone Type
Z1
Z2
:
Z16
:
Z32
0=Free
7=Panic
1=Door
8=Duress
2=Window
9=Tamper(Sabotage)
3=Interior
10=Medical
4=Exterior
11=Custom
5=24 Hour
12=Key(*)
6=Fire
* Key Zone is used as Key Input.
Z1=1
Z2=3
:
:
Z32=3
IP
Page:56
For SPT:30
23 01
23 02
:
23 16
:
23 32
Zone Extra Settings
Z1
Z2
:
Z16
:
Z32
1.option=End door Yes=on, No=off
2.option=Follower Zone Yes=on, No=off
3.option=Entry/Exit Zone Yes=on, No=off
4.option=Silent Zone Yes=on, No=off
5.option=Can not be bypassed manually Yes=on, No=off
6.option=Can not be Auto bypassed Yes=on, No=off
7.option=Cross Zone Yes=on, No=off
Z1=3
Z2=2
Z3= -
:
:
Z32= -
IP
Page:57
24 01
24 02
:
24 16
:
24 32
Zone Trigger Delay
Z1
Z2
:
Z16
:
Z32
2...255
Formula: Time=Value * 30 ms
15
IP
Page:58
30 01
30 02
30 03
30 04
Keypad Permissions
Keypad 1
Keypad 2
Keypad 3
Keypad 4
1.option=Keypad enable/disable
2.option=Quick arm enable/disable
3.option=Arm enable/disable
4.option=Disarm enable/disable
5.option=Programming permission enable/disable
6.option=Access control on/off
7.option=Sabotage alarm enable/disable
1.keypad
1,2,3,4,5
Others
2,3,4
IP
Page:59
31 01
31 02
31 03
31 04
Keypad Partitions
Keypad 1
Keypad 2
Keypad 3
Keypad 4
1.option=A Partition
2.option=B Partition
3.option=C Partition
4.option=D Partition
All
Selected
IP
Page:59
For SPT:30
40 01
40 02
:
40 29
User Start Time
User 1
User 2
:
User 29
HH MM HH=hour, MM=minute
00:00
MP
Page:60
40 30
Guest Start Time
HH MM HH=hour, MM=minute
00:00
MP
Page:61
41 01
41 02
:
41 29
User Finish Time
User 1
User 2
:
User 29
HH MM HH=hour, MM=minute
23:59
MP
Page:61
41 30
Guest Finish Time
HH MM HH=hour, MM=minute
23:59
MP
Page:61
42 01
42 02
:
42 29
User Days
User 1
User 2
:
User 29
1.option=Monday 5.option=Friday
2.option=Tuesday 6.option=Saturday
3.option=Wednesday 7.option=Sunday
4.option=Thursday
All
Selected
MP
Page:62
42 30
Guest Days
1.option=Monday 5.option=Friday
2.option=Tuesday 6.option=Saturday
3.option=Wednesday 7.option=Sunday
4.option=Thursday
All
Selected
MP
Page:62
43 01
43 02
:
43 29
User Partitions
User 1
User 2
:
User 29
1.option=A Partition
2.option=B Partition
3.option=C Partition
4.option=D Partition
All
Selected
MP
Page:62
For SPT:30
43 30
Guest Partitions
1.option=A Partition
2.option=B Partition
3.option=C Partition
4.option=D Partition
All
Selected
MP
Page:63
For SPT:30
44 01
44 02
:
44 29
User Keypads
User 1
User 2
:
User 29
1.option=Keypad 1
2.option=Keypad 2
3.option=Keypad 3
4.option=Keypad 4
All
Selected
MP
Page:63
44 30
Guest Keypad
1.option=Keypad 1
2.option=Keypad 2
3.option=Keypad 3
4.option=Keypad 4
All
Selected
MP
Page:63
