Teknim VAP416 - Page 79

VAP416 Installation & Operation Manual
TD-1/07-004
79 / 81
ADR.
FUNCTION
VALUE
DEFAULT
VALUE
DETAILS
INST.
VALUE
51 01
51 02
51 03
51 04
51 05
51 06
51 07
51 08
51 09
51 10
51 11
51 12
51 13
51 14
51 15
51 16
51 17
51 18
51 19
51 20
51 21
51 22
51 23
51 24
51 25
51 26
51 27
51 28
51 30
51 32
Event Log and Settings
1.Intruder Alarm
2.Panic Alarm
3.Fire Alarm
4.Duress Alarm
5.Sabotage Alarm
6.Medical Alarm
7.Duress Disarm
8.Disarm at Alarm
9.Zone Trouble
10.AC Fail
11.Intrusion Verifier
12.Cross Zone Fault
13.Battery Low
14.Line Fail
15.Battery Fail
16.Communication Fail(1)
17.Special Arm/Disarm
18.Arm/Disarm
19.Bypassed
20.Entered Program
21.Exited Program
22.Periodic Report
23.Panel Restarted
24.Manual Report
25.Phone Arm/Disarm
26.PC Arm/Disarm
27.Remote Access
28.Parallel Line Intruder
30.Custom Zone Alarm
32.Defaults Loaded
33-64 Restore (2)
1.option=Call CMS
2.option=Call User Phone
3.option=Call CMS for Restore
4.option=Call User Phone for Restore
5.option=Record to Memory
1 Communication Fail is only recorded to memory.
(2) Restores no 33-64 is displayed in event log memory if
event is selected to be recorded to memory.
1: 1,2,3,5
2: 1,2,3,5
3: 1,2,3,5
4: 1,2,3,5
5: 1,2,3,5
6: 1,2,3,5
7: 1,2,5
8: 1,5
9: 1,3,5
10: 1,3,5
11: 1,5
12: 1,5
13: 1,3,5
14: 5
15: 1,3,5
16: 5
17: 1,3,5
18: 1,3,5
19: 1,3,5
20: 1,5
21: 1,5
22: -
23: 5
24: -
25: 1,3,5
26: 1,3,5
27: 5
28: -
30: 1,5
32: 5
IP
Page:69
52 01
52 02
52 03
52 04
52 05
52 06
52 07
52 08
52 09
52 10
52 11
52 12
52 13
52 14
52 15
52 16
52 17
52 18
52 19
52 20
52 21
52 22
52 23
52 24
52 25
52 26
52 27
52 28
52 30
52 32
ContactID Event Code
Settings
1.Intruder Alarm
2.Panic Alarm
3.Fire Alarm
4.Duress Alarm
5.Sabotage Alarm
6.Medical Alarm
7.Duress Disarm
8.Disarm at Alarm
9.Zone Trouble
10.AC Fail
11.Intrusion Verifier
12.Cross Zone Fault
13.Battery Low
14.Line Fail
15.Battery Fail
16.Communication Fail(1)
17.Special Arm/Disarm
18.Arm/Disarm
19.Bypassed
20.Entered Program
21.Exited Program
22.Periodic Report
23.Panel Restarted
24.Manual Report
25.Phone Arm/Disarm
26.PC Arm/Disarm
27.Remote Access
28.Parallel Line Intruder
30.Custom Zone Alarm
32.Defaults Loaded
4 digits Event Code
1 Communication Fail is only recorded to Memory.
2 Special Arm/Disarm code is sent to Central Monitoring
Station on Quick Arm, Arming on no activity, Automatic
Arm/Disarm, Arm/Disarm by key, Arm/Disarm by Remote
Controller.
1: 1130
2: 1120
3: 1110
4: 1120
5: 1144
6: 1100
7: 1121
8: 1406
9: 1372
10: 1301
11: 1139
12: 1378
13: 1302
14: 1351
15: 1302
16: 0000
17: 1400
18: 1402
19: 1570
20: 1627
21: 1628
22: 1602
23: 1305
24: 1601
25: 1402
26: 1402
27: 0000
28: 0000
30: 0000
32: 0000
IP
Page:70
60 01
Remote Control Module
Setting
1.option=Enabled/Disabled
2.option=Siren Alarm on Panic
3.option=Wireless detector enable
Nothing
Selected
IP
Page:73
60 02
Supervisory Interval
1...255 hours
6
IP
Page:73
61 01
Zone Expansion Module
Setting
1.option=Enabled/Disabled
Disabled
IP
Page:74
