G10 Hardware Maintenance Guide 7.13.2 144
6
System Operating Specifications
Rev. 002-140228
PHYSICAL SPECIFICATIONS
All equipment is suitable for mounting in a standard 19- or 23-inch wide equipment rack or
cabinet. G10 installation varies depending on the type of rack configuration in which it is
installed:
Two-Post Rack—G10 must be mid-mounted
Four-Post Rack—G10 must be front-mounted
A switch or circuit-breaker must be included in the building installation and it must be in
close proximity to the equipment and within easy reach of the operator. It must be marked as
the disconnecting device for the equipment.
Note the following information regarding rackmount ventilation:
Do not block or cover ventilation openings at the front and rear of an enclosure. Never
place an enclosure near a radiator or heating vent. Failure to follow these guidelines
can cause overheating and affect the reliability and warranty of your enclosure.
Leave a minimum of 6 inches (15 cm) at the front and back of each enclosure to
ensure adequate airflow for cooling. No cooling clearance is required on the sides,
top, or bottom of enclosures.
Leave enough space in front and in back of an enclosure to allow access to enclosure
components for servicing. Removing a component requires a clearance of at least 15
inches (37 cm) in front of and behind the enclosure.
G10 Probe Fuse Panel SAS Storage Enclosure
a
Height
(space required)
3U
132 mm (5.20 inches)
1U
44.45 mm (1.75 inches)
2U
88.90 mm (3.50 inches)
Width 445 mm (17.52 inches) 431.80 mm (17.0 inches) 447.04 mm (17.6 inches)
Depth 420 mm (16.54 inches) 304.80 mm (12.0 inches) 502.92 mm (19.8 inches)
Weight 22 kg (47 lbs.) 4.09 kg (9.0 lbs.) 29 kg (64 lbs.)
Heat Dissipation 2048 BTU/hr max
1808 BTU/hr typical
Per 100A bus @% load
1.0W (3.4 Btu/hr) @ 0%
1.2W (4.1 Btu/hr) @ 25%
4.8W (16.5 Btu/hr) @ 50%
11.4W (38.7 Btu/hr) @ 75%
21.3W (72.6 Btu/hr) @ 100%
SA100R (24 300 GB disks)
956 BTU/hr typical
1706 BTU/hr max
SA200R (24 900 GB disks)
1433 BTU/hr typical
1706 BTU/hr max
SA200J (24 900 GB disks)
870 BTU/hr typical
1706 BTU/hr max
a. For IAP100/PRM100 RTM configurations, you must leave 1U of space below the G10 to allow for SAS cabling from the
SAS AMC on the front of the G10 to the back of the controller enclosure(s).
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
