Tektronix GeoProbe G10 User Manual

G10 Hardware Maintenance Guide 7.13.2 146 
6
System Operating Specifications
Rev. 002-140228
Tektronix equipment, cables, and wiring diagrams comply with industry standard DC
electrical color coding. Please ensure proper cabling if your equipment and cabling uses
nonstandard DC electrical color coding. Improper cabling can cause damage to equipment
or personal injury. Contact Tektronix to request specially labeled power cables (-48V = Red,
Return = Black) for the G10 chassis and the storage enclosures.
AC Power Requirements
Table 6.2 lists the AC power requirements for the GeoProbe G10 and SAS storage
enclosures. All probe and disk enclosure power and chas
sis ground cabling will use 12AWG
cable or larger.
Table 6.2 - AC Power Requirements
Equipment VAC Fuse Watts
G10 (IIC100 and IAP100) 100 to 240 VAC 6A max 470W typical, 600W max
G10 (IIC100 and IAP200) 100 to 240 VAC 6A max 520W typical, 600W max
G10 (IIC100 and IAP320)
a
100 to 240 VAC 6A max 545W typical, 600W max
G10 (IIC200 and IAP200) 100 to 240 VAC 6A max 545W typical, 600W max
G10 (IIC200 and IAP320) 100 to 240 VAC 6A max 545W typical, 600W max
G10 Media Expansion Chassis
(2 IIC100s and 2 TRM100 RTMs)
100 to 240 VAC 6A max 510W typical, 600W max
G10 Media Expansion Chassis
(2 IIC200s and 2 SRM200 RTMs)
100 to 240 VAC 6A max 506W typical, 600W max
G10 Control Plane Expansion Chassis
(2 IAP200s and 2 PRM200 RTMs)
100 to 240 VAC 6A max 520W typical, 600W max
G10 Control Plane Expansion Chassis
(2 IAP320s and 2 PRM300 RTMs)
100 to 240 VAC 6A max 585W typical, 600W max
SA100R RAID Storage Enclosure 100 to 240 VAC 5A max 280W typical, 500W max
SA100J JBOD Storage Enclosure 100 to 240 VAC 5A max 280W typical, 500W max
SA200R RAID Storage Enclosure
b
100 to 240 VAC 5A max 420W typical, 500W max
SA200J/SA210J JBOD Storage
Enclosure
b
100 to 240 VAC 5A max 255W typical, 500W max
a. The control plane probe does not support the IIC100/IAP320 configuration.
b. For Storage Enclosure and 24 900G drives (SA200J) or 12 4TB drives (SA210J).
