G10 Hardware Maintenance Guide 7.13.2 22
Chassis Subsystem
OVERVIEW
The Chassis subsystem is a high-availability Advanced TCA that integrates cooling, power
distribution, and shelf management into an off-the-shelf platform, which allows you to add
GeoProbe G10 service-related hardware and software. The Chassis subsystem of the
GeoProbe G10 enables scalable reliability through the use of either independent or redundant
functions throughout the chassis. Most electronic modules, blades and cards are Field
Replaceable Units (FRUs).
The Chassis subsystem contains the
following main hardware component
s:
Shelf Manager
Power Entry Modules (PEMs)
Fan Trays
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
