Tektronix GeoProbe G10 User Manual

G10 Hardware Maintenance Guide 7.13.2 67 
3
Blades and RTMs
Rev. 002-140228
IAP100 RTMs
The IAP100 supports the following Rear Transition Modules (RTMs):
 PRM100 RTM
 SSD-3400 RTM
PRM100 RTM
The PRM100 RTM connects to the rear of IAP100. The RTM works in conjunction with the
IAP100 and provides additional connectivity options and a hard disk used for the operating
system. The PRM100 performs the following functions:
 Provides cable connections to the disk array
 Provides hard drive for operating system
 Includes an IPMC
Figure 3.36 displays the PRM100 RTM.
Figure 3.36 - PRM100 RTM
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
